ALL IN ONE 26650 lifepo4 12V 33ah lithium iron phosphate battery pack

2021-06-06 13:30

Product Specification

Características eléctricasTensión normal 12.8V
Capacidade nominal 33Ah
Enerxía 422.4Wh
Resistencia interna ≤55mΩ
Ciclo de vida >2000 cycles
Months Self discharge ≤3,5% mensual aos 25 ℃
Carga estándarTensión de carga 14,6 ± 0,2V
Charge Mode( CC/CV) At 0℃~45℃ temperature, charged to 14.6v at constant   current of 0.2C5A, and then, changed continuously with   constant voltage of 14.6v until the current was not more than 0.02C5A
Corrente de carga 6.6A
Max.Charge current 16.5A
Descarga estándarCorrente de descarga 6.6A
Max.continuous current 30A
Max. Pulse current 60A (<3S)
Tensión de corte de descarga 10.0V
EnvironmentalTemperatura de carga 0℃ to 45 ℃
Temperatura de descarga -20℃ to 60 ℃
Temperatura de almacenamento 0℃ to 45 ℃
Resistencia ao po de auga IP55
MecánicaPlastic Case ABS
Dimension (L*W*H*TH) 195*130*156*167mm
Peso Approx. 4.9KG
TerminalM6

Características

1. Cells -  Grade A cells to make sure batteries in high and full capacity.

2. Extremely safe and stable chemistry: BMS or PCB built inside to protect the battery over charge and discharge.

3. Batteries can be customized according to customer requirements, such as voltage, capacity, mating plug/connector, etc.

4. Wide operating temperature: High temperature resistance(-20~60 degrees Celsius).

5. Steady performance: High power output, low self-discharge rate, less than 3% monthly.

6. No memory effects and highly efficient charge: It can be recharged anytime, no reduction of the capacity.

7. Green product: Environment friendly, clean and green energy, no pollution on our environment.

8. Short delivery, perfect service, long life cycle

Paquetes de baterías LiFePO4 relacionados

Aplicación

1. Home ESS System

2. Back-up power for Boat&Camping car

3. Power Tools

4. E-Bike, E-scooter

5. UPS, DC switching power supply system

6. Solar Light

A nosa fábrica

Os nosos servizos e forza

1.ISO9001 certified factory: passed ISO9001:2015 inspection, strictly control the working environment.

2.Quality assurance: Using high quality material and build a comprehensive quality control system from parts to finished products. And 100% production inspection.

3.Professional R&D center: Size, capacity, PCM, wires and connector can be customized according to customer demands. OEM and ODM are warmly welcomed.

4.Low MOQ: Strength factory, strong production capacity, most of battery models have sufficient stock, can be fast dispatched.

5.Authorized certification: most models passed certification, in line with international standards.

6.Excellent service system: Respond quickly to customer questions and provide solution. Provide 12 months warranty, guide you to use our batteries, deal with customer.

Embalaxe e envío

Mode of transport

By HK UPS (It takes about 4-6days to arrive)
By air cargo (It takes about 7-10days to arrive)
By sea shipment (It takes about 1 month to arrive)

We could arrange sea, air and express transportation for you, with 10 years experience and
trustworthy forwarder partners, shipment won’t be a problem.

FAQ
Q1. ¿Podo ter unha orde de mostra?
R. Si, acollemos a orde de mostra para probar e comprobar a calidade.
P2. E o tempo de entrega?
A. A mostra necesita 3 días, o tempo de produción en masa necesita 5-7 semanas, depende da cantidade da orde.
Q3. Tes algún límite de MOQ?
R. Si, temos MOQ para a produción en masa, depende dos distintos números de parte. 1 ~ 10 unidades pedido dispoñible está dispoñible. MOQ baixo, 1 pieza para a comprobación da mostra está dispoñible.
Q4. Como envías a mercadoría e canto tardas en chegar?
A. Normalmente tardan 5-7 días en chegar. O transporte aéreo e marítimo tamén é opcional.
Q5. Como proceder cunha solicitude?
A. En primeiro lugar avísanos os teus requirimentos ou solicitude.
En segundo lugar, citamos segundo as súas necesidades ou as nosas suxestións.
Thirdly customer confirms the samples and places a deposit for formal order.
En cuarto lugar Organizamos a produción.
Q6. ¿Está ben imprimir o meu logotipo no produto?
A. Si. Informenos formalmente antes da nosa produción e confirme o deseño en primeiro lugar baseado na nosa mostra.
Q7.Que certificados tes?
R: Temos CE / FCC / ROHS / UN38.3 / MSDS ... etc.
Q8.Como a garantía?
A:2 year warranty.

Nota: We are a battery manufacturer. All products do not support retail, please contact us for product prices!
