Batería de vehículo eléctrico 60v 40ah 50ah 65ah paquete de batería

2023-08-24 08:06

Especificación

Parámetro de función
Nominal Battery Energy	3900wh
Nominal Capacidade	65 Ah
Nominal Voltaxe	60V
Resistencia interna	≤22 mΩ
Ciclo de vida	> 6000
Meses Autocarga	<3%
Datos de carga
Tensión de carga normal DC	54,75 ± 1 Vdc
Modo de carga	0,2 C a 54,75 V, despois 54,75 V, corrente de carga a 0,02 C (CC/CV)
Corriente de carga recomendada	≤50A
Máx. permitido Corrente de carga	50Adc
Tensión de corte de carga	54,75 ± 1 Vdc
Datos de descarga
Corrente de descarga continua	50A
Máx. permitido corrente de descarga	100A (opción: 100Adc)
Rango de tensión de descarga DC	37,5 V-54,75 Vdc
Condición de traballo
Temperatura de carga	0 ℃ a 45 ℃ (32 ℉ a 113 ℉) @ 60 ± 25 % de humidade relativa
Temperatura de descarga	-20 ℃ a 60 ℃ (-4 ℉ a 140 ℉) @ 60 ± 25 % de humidade relativa
Temperatura de almacenamento	0 ℃ a 40 ℃ (32 ℉ a 104 ℉) @ 60 ± 25 % de humidade relativa
Nivel de protección do recinto	IP67

características

1.Rechargeable battery
2.Use of Iron(Fe) as a cathode material
3.Higher discharge current
4.Do not explode under extreme conditions and weight less

Vantaxes

1.Extremely high rate capability
2.Safe lithium battery
3.Good storage characteristics
4.Good high temp performance
5.Long cycle life to 2000 times
6.High capacity & light weight
7.Environmentally friendly
8.No memory effect

We can provide you with customized services

Customized 7.4V-12V-24V-36V-48V-52V-60V-72V...LITHIUM BATTERY PACK

The capacity and dimension can customize according to your request:

1. Tamaño da batería personalizado e material da carcasa

2. Corriente de carga e descarga BMS personalizada

3. Enchufe e toma de conexión personalizados, fío de conector

PRINCIPAL Principais aplicacións do paquete de baterías de litio
Aplicacións de propulsión eléctrica	batería de arranque do motor; Coche de velocidade lenta; robots intelectuais; bicicleta eléctrica / motocicleta / scooter; carro de golf / carros / turismo; ferramentas eléctricas.
Almacenamento de enerxía	sistema de enerxía solar e eólica; rede on / off da cidade; comunidade e familia, RV Caravan, Marine yachts.
Sistema de copia de seguridade e SAI	Telecommute base, CATV-system, computer server center, medical instrument, military equipment.
Outras aplicacións	seguridade e electrónica; TPV móbil, luz de minería / facho / luz LED / luz de emerxencia.

A nosa empresa

WHY CHOOSE US?
1.Our company has 13 years experience in battery R&D,producing and the overseas marketing.
2.Flexible customizing and Manufacturing
3.6,000,000Ah monthly production capacity
4.Each process for making battery were under strict management and control,all of the battery were under full inspection before delivery.
5.With professional R&D team, experienced workers and advanced requirements, we are determined to provide you high-quality battery.

6.Support prompt shipment and sample quality products,track the cargo in time after delivery.More than one year Guarantee,we will give instruction for how to use our products.



FAQ

Q: What is your warranty?
A: We guarantee the quality before the item is shipped. The warranty will be offered based on different type of battery. Any damages caused by improper use are not covered by our warranty.

Q: What is delivery time if we place an order?
A: It depends order quantities. Usually, we can deliver goods within 3 -5 working days for small orders, for more QTY. order, let's confirm when you place offical order.

Q: Are your factory or trading company?
A: We are professional lithium-ion rechargeable batteries manufacturer with our own factory and brand. We provide all kinds of OEM/ODM services for clients around globe.
